3M O/B POUCH Performance Plus Wire Connector, 22 to 12 AWG Wire, Steel Contact, Blue/Orange – pack of 100

Introduction

• It offers a strong bite in a pigtail application so you get a long-lasting connection
• An expandable spring lets you take in more wire uptake and reuse
• The O/B+ is dual color-coded so this 1 connector replaces your traditional orange and blue connectors
• Great for all types of jobs – from industrial and residential construction, to automotive, marine and appliance applications
• Use with copper conductors ranging from 22 to 12 AWG
• Built with polypropylene and thermoplastic elastomer material
• Orange/blue connector is flame-retardant and operates in temperatures up to 221 deg F
• Use on building wire rated 600 V and on signs, fixtures or luminaires rated 1000 V

Warranty

Limited lifetime

Pack Size

100

UNSPSC

39121445

Height

3.5″

Mounting Type

Screw

Width

0.49″

Color

Blue/Orange

Wire Size

22 to 12 AWG

Contact Material

Steel

Nomenclature

O/B+ WIRE CONNECTOR 100/BOX

Housing Material

Polypropylene/Thermoplastic Elastomer

Product Overview ORANGE/BLUE WIRE CONN 100/BOX
Specifications:

Application: For industrial and residential construction to automotive, marine and appliance applications

The improved 3M O/B+ connector will help electricians do more with less. The O/B+ connector combines a very small shell with an increased wire range. The improved spring bites wire quickly with less effort and accommodates from two #22 AWG wires up to three #12 AWG wires or four #14 AWG wires. The very small shell fits easily into tight spaces and its flexible skirt helps protect workers from contact with over stripped wires. With such a wide wire range, you can save money by buying fewer connectors. O/B + replaces the orange, blue and gray spring connector
