Eaton BR48L125RP BR Load Center, 125 A, 4 -Space, 8 -Circuit, Main Lug, NEMA 3R Enclosure, Plug Mounting Light Gray

Introduction

• Accepts type BR Duplex and Quadplex breakers
• Larger knockout provides easier installation and time savings
• Type BR sub-panel
• Top or bottom feed, straight-in wiring saves labor and material, one panel for either top or bottom applications
• 2/0 lug easily removable and can be installed in any location on the neutral bar
• NEMA 3R enclosure for outdoor use.
• Type BR AFCI breakers, compact design for easier wiring and improved wireway access, optional LED indicates one of six trip codes for circuit diagnostics, provides a clean gutter space
• Excellent conductivity and corrosion resistance, copper bus options available
• Drywall marking on enclosure – indicates proper mounting depth for flush applications
• Tangential center knockout, easier installation for conduit applications
• Commercial-grade main breaker, 25 kAIC series rated main breaker for great protection
• Neutral bus (strap) is easily removable for sub-panel applications
• Bonding Z-strap provides easy field conversion for service entrance applications

Voltage

120/240

Mounting Type

Plug

Warranty

10 years

Certifications

Made in the USA, UL

Amperage

125 Amp

Phase

1

Manufacturer Warranty

10 years

Certifications and Listings

ANSI Certified, CSA Listed, UL Listed

Indoor/Outdoor

Outdoor

Load Center Type

Main Lug

Load center width (in.)

11.0

Maximum Amperage

125

Maximum Voltage

120/240 Volt

Number of Circuits

8

Number of Phases

1

Number of Spaces

4

Pack Size

1

Height

4.20

AMPS

125 amps

Volts

120/240 V

Depth

3.56″

Width

12.20

UL Listed

Yes

Packaging Type

Boxed

Indoor or Outdoor

Outdoor

Breakers Included

No

Circuit Protection Type

Main Lug

Defective Code

A

Each Weight

9.000 LB

Hazardous Material

No

Maximum Number of Circuits

8 circuits

Returnable

Yes

Velocity

C

Product Type

Main Lug Load Center

UNSPSC

39121101

Length

14.10

ECCN

EAR99

Country Origin Code

US

Color

Light Gray

Bus Bar Material

Aluminum

Breaker/Load Center Type

Main Lug

Application

For use as service equipment

Enclosure Type

NEMA 3R

Current Rating

125 A

Cable Size

14 to 1/0 AWG

Interrupt Rating

10 kA

Nomenclature

BR48L125RP MAIN LOADCNTR 125A

Wiring Configuration

3-wire

Alternative UPC

786689212575

Wire Size

#14 To 1/0

Width (in)

11

Depth (in)

3.56

Height (in)

13

Certification

UL Listed

Series

BR

Mount Type

Surface

Max Number of Poles

8

Product Overview LOADCNTR MAIN LUG BR G60 125A

Load Centers are enclosures specifically designed to house the branch circuit breakers and wiring required to distribute power to individual circuits. They contain either a main breaker when used at the service entrance point or a main lug when used as a sub-panel to add circuits to existing service. The main breaker protects the main entire panel and can be used as a service disconnect. The branch breakers protect the wires leading to individual electrical loads such as fixtures and outlets.
